Zdrutowane przez Pentiuma

Pan Ciastovy · 18 Czerwca

@Pentium Deh widziałem ten model na lolegro 4060 8GB

Grolshek · 18 Czerwca

A jaki był opis uszkodzenia?

**Pentium D** · 18 Czerwca

2 godziny temu, Pan Ciastovy napisał(a):

@Pentium Deh widziałem ten model na lolegro 4060 8GB

4060 Ti 16 Giba

Godzinę temu, Grolshek napisał(a):

A jaki był opis uszkodzenia?

O dziwo mocno prawdziwy. Bez drivera chodzi, ale przy próbie instalacji gaśnie obraz i widać kilka czerwonych pojedynczych pikseli które wygaszają się powoli. Teraz próbuję z integrą coś zrobić, ale nawet biosu z karty nie idzie wyjąć przez gpuz. W menadżerze kod 43. Karta musiała doznać uderzenia/upadku bo backplate trochę zgięty a w ofercie użyli grafik producenta zamiast real foto. Coraz częściej spotykane przez te katalogi produktów. Na szczeście jest opcja zwrotu na 14 dni więc jak nic nie wyczaruje to zwrot i elo.


Pan Ciastovy · 18 Czerwca

@Pentium D To teraz żeby ją naprawić trzeba ją na podgrzewacz żeby się wyprostowała, zdjąć najbliższe pamięci przy slocie pci-e i sprawdzić czy nie mają po urywanych padów na pcb

sideband · 18 Czerwca

Najpierw to się robi test, który kanał robi problemy. A nie w ciemno działa

A uszkodzeń może być wiele łącznie z uszkodzonym kontrolerem w GPU i nic z tym nie zrobisz poza wymianą GPU, która jest nieopłacalna. A tylko do 3xxx są biosy z wyłączonymi kanałami by dało się reaktywować karty niezależnie od scenariusza i bez grzebania.

**Pentium D** · 19 Czerwca

Właśnie zrobiłem testy modsem i są faile. Później wrzucę logi jak karty podmienie. RXa tak obili w transporcie i działał jak nowy a Rtx lekka wgniotka i dupa. Na moje coś pod rdzeniem puściło skoro wywala przy starcie systemu gdy tylko sterownik wyczuje w pobliżu xd

MODS arguments :

MODS start: Thu Jun 19 01:48:11 2025

Command Line : gputest.js -skip_rm_state_init -oqa -test 2

CPU
Arch           : x86_64
Name           : AMD Ryzen 7 7700 8-Core Processor
Cores          : 16

Version
MODS           : 520.112

System
OperatingSystem: Linux (x86_64)
Kernel         : 5.9.1-gentoo-x86_64
KernelDriver   : 4.00
SBIOS Version  : 3.16
SBIOS Date     : 12/18/2024
HostName       : tinylinux
Available RAM  : 30726/31314 MB (Free/Size)
Hypervisor     : No
Sys-uuid       :
HDD-Serno      :

                 GPU 0 [01:00.0]  dev.sub 0.0
                 ----------------------------------------
DevInst        : 0
PCI Location   : 0x00, 0x01, 0x00, 0x00
GPU DID        : 0x2805
PDI            : 0x96a91ae7a68aef3d
Raw ECID       : 0x010085c000000009024909e1
Raw ECID (GHS) : 0x1780902490800000017040200
ECID           : TSMC-U2G992-23_x8_y8
Device Id      : AD106
Revision       : a1
Sub Revision   : 0
NV Base        : 0xf5000000
FB Base        : 0xa0000000
IRQ            : 255
WARNING: AmdSmbPort::Transaction - Device Busy
ERROR: bp @ <fileid:0x0001f0>:2702

ERROR: ** ModsDrvBreakPoint on GPU 0 [01:00.0] **

[ 0] ------------------------- BEGIN ASSERT INFO DUMP -------------------------
[  ] HostName       : tinylinux
[  ] Available RAM  : 30726/31314 MB (Free/Size)
[  ] NUMA Node 0 RAM: 30726/31314 MB (Free/Size)
[  ] Hypervisor     : No
[  ] Successfully opened /sys/firmware/efi/systab
[  ] SMBIOS entry point at 0x970d8000
[  ] Sysmem page size is 4 KB
[  ] Smbios version [0x304] is not supported
[  ] Failed to Read system UUID, this requires root permissions to run
[  ] Sys-uuid       :
[  ] Failed to Read Hdisk Serial num, this requires root permissions to run
[  ] HDD-Serno      :
[  ]
[  ] Turning off register exclusion regions.
[  ] >boards.jse
[  ] Preprocessing boards.jse.
[  ] Successfully opened /home/520.112/boards.jse
[  ] Compiling boards.jse.
[  ] usb 1-12: New USB device found, idVendor=0e8d, idProduct=0717, bcdDevice= 1.00
usb 1-12: New USB device strings: Mfr=5, Product=6, SerialNumber=7
usb 1-12: Product: Wireless_Device
usb 1-12: Manufacturer: MediaTek Inc.
usb 1-12: SerialNumber: 000000000
[  ] Compiled boards.jse, pScript = 0x0x10f128d0.
[  ] Executing boards.jse.
[  ] <boards.jse
[  ] CreateNvLinkLibInterface : Creating NvLink library interface NvLinkLibIfUser
[  ] CreateAllDevInterfaces : Created NvLink device interface NvSwitchDevIf
[  ] CreateAllDevInterfaces : Created NvLink device interface NvGpuDevIf
[  ] Warning: Can't find Pci device with class code 0x68000, index 0
[  ] Find NvSwitch ports
[  ] -------Finish NvSwitch detection-----
[  ] NVRM <func>: Unrecognized AMD processor in cpuidInfoAMD
[  ] Physical Graphics controller at 0000:01:00.0
[  ] reg virtual base = 0x7f69017fd000
[  ] IOVA enabled
[  ] Detected 47 sysmem address bits for chip id 0xd06 at 0000:01:00.0, IOVA enabled
[  ] BAR0 base = 0x0_F5000000,
     size = 0x01000000
[  ] BAR1 base = 0x0_A0000000,
     size = 0x10000000
[  ] BAR2 base = 0x0_B0000000,
     size = 0x02000000
[  ] Vendor ID = 0x10DE
[  ] Device ID = 0x2805
[  ] Chip ID   = 0x00000196
[  ] [0000:01:00.0] cap id 0x5 found at offs 0x68
[  ] [0000:01:00.0] cap id 0x11 not found
[  ] mods [1]: set dma mask 47 for dev 0000:01:00.0
[  ] [0000:01:00.0] cap id 0x10 found at offs 0x78
[  ] [0000:01:00.0] extended cap id 0x1e found at offs 0x0258
[  ] Register manual file ad106_ref.txt not found
[  ] Physical Graphics controller at 0000:0d:00.0
[  ] Bypassing non-NVIDIA card
[  ] Warning: Can't find Pci device with class code 0x30000, index 2
[  ] Warning: Can't find Pci device with class code 0x30200, index 0
[  ] Found Test Devices :
[  ]    GPU 0 [01:00.0]
[  ] Find bridge ports
[  ] [0000:00:01.1] bridge sec=01 sub=01 vendor=1022 devid=14da uniq_link_poll=false
[  ] [0000:00:01.2] bridge sec=02 sub=02 vendor=1022 devid=14da uniq_link_poll=false
[  ] [0000:00:02.1] bridge sec=03 sub=0b vendor=1022 devid=14da uniq_link_poll=false
[  ] [0000:00:02.2] bridge sec=0c sub=0c vendor=1022 devid=14da uniq_link_poll=false
[  ] [0000:00:08.1] bridge sec=0d sub=0d vendor=1022 devid=14da uniq_link_poll=false
[  ] [0000:00:08.3] bridge sec=0e sub=0e vendor=1022 devid=14da uniq_link_poll=false
[  ] [0000:03:00.0] bridge sec=04 sub=0b vendor=1022 devid=43f4 uniq_link_poll=false
[  ] [0000:04:00.0] bridge sec=05 sub=05 vendor=1022 devid=43f5 uniq_link_poll=false
[  ] [0000:04:04.0] bridge sec=06 sub=06 vendor=1022 devid=43f5 uniq_link_poll=false
[  ] [0000:04:05.0] bridge sec=07 sub=07 vendor=1022 devid=43f5 uniq_link_poll=false
[  ] [0000:04:07.0] bridge sec=08 sub=08 vendor=1022 devid=43f5 uniq_link_poll=false
[  ] [0000:04:08.0] bridge sec=09 sub=09 vendor=1022 devid=43f5 uniq_link_poll=false
[  ] [0000:04:0c.0] bridge sec=0a sub=0a vendor=1022 devid=43f5 uniq_link_poll=false
[  ] [0000:04:0d.0] bridge sec=0b sub=0b vendor=1022 devid=43f5 uniq_link_poll=false
[  ] Warning: Can't find Pci device with class code 0x60400, index 14
[  ] Warning: Can't find Pci device with class code 0x60401, index 15
[  ] Find siblings at 0000:00:xx.x
[  ]   Sibling found: domain=0000 sec=01 sub=01
[  ]   Sibling found: domain=0000 sec=02 sub=02
[  ]   Sibling found: domain=0000 sec=03 sub=0b
[  ]   Sibling found: domain=0000 sec=0c sub=0c
[  ]   Sibling found: domain=0000 sec=0d sub=0d
[  ]   Sibling found: domain=0000 sec=0e sub=0e
[  ]   Found chipset controller's port at 0000:00:01.1
[  ] [0000:00:01.1] cap id 0x10 found at offs 0x58
[  ] [0000:00:01.1] extended cap id 0x1e found at offs 0x0370
[  ] [0000:00:01.1] extended cap id 0x1 not found
[  ] [0000:00:01.2] cap id 0x10 found at offs 0x58
[  ] [0000:00:01.2] extended cap id 0x1e found at offs 0x0370
[  ] [0000:00:01.2] extended cap id 0x1 not found
[  ] [0000:00:02.1] cap id 0x10 found at offs 0x58
[  ] [0000:00:02.1] extended cap id 0x1e found at offs 0x0370
[  ] [0000:00:02.1] extended cap id 0x1 not found
[  ] [0000:00:02.2] cap id 0x10 found at offs 0x58
[  ] [0000:00:02.2] extended cap id 0x1e found at offs 0x0370
[  ] [0000:00:02.2] extended cap id 0x1 not found
[  ] [0000:00:08.1] cap id 0x10 found at offs 0x58
[  ] [0000:00:08.1] extended cap id 0x1 not found
[  ] [0000:00:08.3] cap id 0x10 found at offs 0x58
[  ] [0000:00:08.3] extended cap id 0x1 not found
[  ] Root check: 0000:00:01.1 IsRoot=true
[  ] Connecting ports for Chipset 0000:00:01.1:
[  ]   DP0 0000:00:01.1 connects to test device GPU 0 [01:00.0]
[  ] ------Finish bridge detection-----
[  ] Detected EFI console in BAR1 of GPU 0 [01:00.0]
[  ] Suspended Linux console
[  ] InitializeAllDevices : RM not initialized, skipping GPU nvlink device initialization
[  ]                  GPU 0 [01:00.0]  dev.sub 0.0
[  ]                  ----------------------------------------
[  ] DevInst        : 0
[  ] PCI Location   : 0x00, 0x01, 0x00, 0x00
[  ] GPU DID        : 0x2805
[  ] PDI            : 0x96a91ae7a68aef3d
[  ] Raw ECID       : 0x010085c000000009024909e1
[  ] Raw ECID (GHS) : 0x1780902490800000017040200
[  ] ECID           : TSMC-U2G992-23_x8_y8
[  ] Device Id      : AD106
[  ] Revision       : a1
[  ] Sub Revision   : 0
[  ] NV Base        : 0xf5000000
[  ] FB Base        : 0xa0000000
[  ] IRQ            : 255
[  ] MSI-X not supported on GPU 0 [01:00.0], skipping
[  ] Detected supported interrupt types: legacy MSI
[  ] mods [1]: enabled dev 0000:01:00.0
[  ] Disabling interrupt tree 0
[  ] IRQ statistics:
[  ]   num IRQs:      10
[  ]   avg IRQ delay: 0us
[  ]   min IRQ delay: 0us
[  ]   max IRQ delay: 0us
[  ] Legacy interrupts verified OK
[  ] Disabling interrupt tree 0
[  ] IRQ statistics:
[  ]   num IRQs:      10
[  ]   avg IRQ delay: 0us
[  ]   min IRQ delay: 0us
[  ]   max IRQ delay: 0us
[  ] MSI verified OK
[  ] Skipping MSI-X verification
[  ] Hooking MSI
[  ] Warning: Can't find Pci device with class code 0x40300, index 3
[  ] AD106 Azalia: DeviceId: 0x22bd.
[  ] Bypassing unsupported vendor: 0x1002Device already uninitialized
[  ] Bypassing unsupported vendor: 0x1022Device already uninitialized
[  ] Found 1 controllers (DevId 127)
[  ] SetAspm on GPU: 0x10840042
[  ] Reset polled 2 times in 1 us on AzaRegWaitPoll and returned 0.
[  ] Reset polled 2 times in 1 us on AzaRegWaitPoll and returned 0.
[  ] mods [1]: set dma mask 47 for dev 0000:01:00.1
[  ] Found codec on sdin 0
[  ] The codec contains 1 function group(s).
[  ] usb 1-11.1: new full-speed USB device number 7 using xhci_hcd
[  ] PEX: set downstream ASPM=0x70840042
[  ] [0000:01:00.0] cap id 0x10 found at offs 0x78
[  ] Failed to get DRAM information from VBIOS NVDM. Will attempt to read from the DRAM.
[  ] Warning: Can't find Pci device with class code 0x30000, index 2
[  ] Warning: Can't find Pci device with class code 0x30200, index 0
[  ] Warning: Can't find Pci device with class code 0x40300, index 3
[  ] Warning: Can't find Pci device with class code 0x60000, index 14
[  ] Warning: Can't find Pci device with class code 0x60100, index 1
[  ] Warning: Can't find Pci device with class code 0x60200, index 0
[  ] Warning: Can't find Pci device with class code 0x60300, index 0
[  ] Warning: Can't find Pci device with class code 0x60400, index 14
[  ] Warning: Can't find Pci device with class code 0x60401, index 0
[  ] Warning: Can't find Pci device with class code 0x60500, index 0
[  ] Warning: Can't find Pci device with class code 0x60600, index 0
[  ] Warning: Can't find Pci device with class code 0x60700, index 0
[  ] Warning: Can't find Pci device with class code 0x60800, index 0
[  ] Warning: Can't find Pci device with class code 0x60940, index 0
[  ] Warning: Can't find Pci device with class code 0x60980, index 0
[  ] Warning: Can't find Pci device with class code 0x60a00, index 0
[  ] Warning: Can't find Pci device with class code 0x60b00, index 0
[  ] Warning: Can't find Pci device with class code 0x60b01, index 0
[  ] Warning: Can't find Pci device with class code 0x68000, index 0
[  ] Setup dma base only supported on PPC, skipping
[  ] ACPI: Unable to evaluate dev method _DSM, id 0xffffffff on 0000:01:00.0
[  ] ACPI: Unable to evaluate dev method _DSM, id 0xffffffff on 0000:01:00.0
[  ] ACPI: Unable to evaluate dev method _DSM, id 0xffffffff on 0000:01:00.0
[  ] ACPI: Unable to evaluate dev method _DSM, id 0xffffffff on 0000:01:00.0
[  ] ACPI: Unable to evaluate dev method _DSM, id 0xffffffff on 0000:01:00.0
[  ] ACPI: Unable to evaluate dev method _DSM, id 0xffffffff on 0000:01:00.0
[  ] Found (0, 0, 20, 0) with cc = 0xc0500, vid = 0x1022, did = 0x790b
[  ] Found AMD KernCZ SMBus Host ControllerFound 1 devices
[  ] AmdSmbPort::Transaction - Device Busy
[  ] EC Device not found on Smbus
[  ] ACPI: Unable to evaluate dev method _PR0, id 0xffffffff on 0000:00:01.1
[  ] mods [1] error: ACPI method _DSM failed
mods [1] error: ACPI method _DSM failed
mods [1] error: ACPI method _DSM failed
mods [1] error: ACPI method _DSM failed
mods [1] error: ACPI method _DSM failed
mods [1] error: ACPI method _DSM failed
mods [1] error: ACPI method _PR0 failed
[  ] usb 1-11.1: New USB device found, idVendor=1d57, idProduct=fa60, bcdDevice=20.05
usb 1-11.1: New USB device strings: Mfr=1, Product=2, SerialNumber=0
usb 1-11.1: Product: 2.4G Mouse
usb 1-11.1: Manufacturer: LXD
[  ] input: LXD 2.4G Mouse as /devices/pci0000:00/0000:00:02.1/0000:03:00.0/0000:04:0c.0/0000:0a:00.0/usb1/1-11/1-11.1/1-11.1:1.0/0003:1D57:FA60.0005/input/input16
[  ] NVRM <func>: OBJVBIOS: Unknown BIT token 0x73! Skipping...
[  ] NVRM <func>: Revlock: VBIOS or RM Revlock level too low.
[  ] NVRM <func>: MinimumRmRevlockLvl: 9
[  ] NVRM <func>: currentRmRevlockLvl: 7
[  ] NVRM <func>: minimumVbiosRevlockLvl: 0
[  ] NVRM <func>: CurrentVbiosRevlockLvl: 0
[  ] NVRM <func>: bp @ <fileid:0x0001f0>:2702
[  ] bp @ <fileid:0x0001f0>:2702
[  ]
[  ] ** ModsDrvBreakPoint on GPU 0 [01:00.0] **

[ 0] -------------------------- END ASSERT INFO DUMP --------------------------
Error 000000000542 : Gpu.Initialize NVRM VBIOS invalid or rejected [0.359 seconds]
Error 000000000542 : Global.PrintGpuInitError NVRM VBIOS invalid or rejected [0.000 seconds]
Error 000000000542 : Global.InitializeGpuTests NVRM VBIOS invalid or rejected [0.374 seconds]

Error Code = 000000000818 (Mods detected an assertion failure)


 #######     ####    ########  ###
 #######    ######   ########  ###
 ##        ##    ##     ##     ###
 ##        ##    ##     ##     ###
 #######   ########     ##     ###
 #######   ########     ##     ###
 ##        ##    ##     ##     ###
 ##        ##    ##  ########  ########
 ##        ##    ##  ########  ########


MODS end  : Thu Jun 19 01:48:12 2025  [1.269 seconds (00:00:01.269 h:m:s)]

MODS arguments :

MODS start: Thu Jun 19 01:48:11 2025

Command Line : gputest.js -skip_rm_state_init -oqa -test 2

CPU
Arch           : x86_64
Name           : AMD Ryzen 7 7700 8-Core Processor
Cores          : 16

Version
MODS           : 520.112

System
OperatingSystem: Linux (x86_64)
Kernel         : 5.9.1-gentoo-x86_64
KernelDriver   : 4.00
SBIOS Version  : 3.16
SBIOS Date     : 12/18/2024
HostName       : tinylinux
Available RAM  : 30726/31314 MB (Free/Size)
Hypervisor     : No
Sys-uuid       :
HDD-Serno      :

                 GPU 0 [01:00.0]  dev.sub 0.0
                 ----------------------------------------
DevInst        : 0
PCI Location   : 0x00, 0x01, 0x00, 0x00
GPU DID        : 0x2805
PDI            : 0x96a91ae7a68aef3d
Raw ECID       : 0x010085c000000009024909e1
Raw ECID (GHS) : 0x1780902490800000017040200
ECID           : TSMC-U2G992-23_x8_y8
Device Id      : AD106
Revision       : a1
Sub Revision   : 0
NV Base        : 0xf5000000
FB Base        : 0xa0000000
IRQ            : 255
WARNING: AmdSmbPort::Transaction - Device Busy
ERROR: bp @ <fileid:0x0001f0>:2702

ERROR: ** ModsDrvBreakPoint on GPU 0 [01:00.0] **

[ 0] ------------------------- BEGIN ASSERT INFO DUMP -------------------------
[  ] HostName       : tinylinux
[  ] Available RAM  : 30726/31314 MB (Free/Size)
[  ] NUMA Node 0 RAM: 30726/31314 MB (Free/Size)
[  ] Hypervisor     : No
[  ] Successfully opened /sys/firmware/efi/systab
[  ] SMBIOS entry point at 0x970d8000
[  ] Sysmem page size is 4 KB
[  ] Smbios version [0x304] is not supported
[  ] Failed to Read system UUID, this requires root permissions to run
[  ] Sys-uuid       :
[  ] Failed to Read Hdisk Serial num, this requires root permissions to run
[  ] HDD-Serno      :
[  ]
[  ] Turning off register exclusion regions.
[  ] >boards.jse
[  ] Preprocessing boards.jse.
[  ] Successfully opened /home/520.112/boards.jse
[  ] Compiling boards.jse.
[  ] usb 1-12: New USB device found, idVendor=0e8d, idProduct=0717, bcdDevice= 1.00
usb 1-12: New USB device strings: Mfr=5, Product=6, SerialNumber=7
usb 1-12: Product: Wireless_Device
usb 1-12: Manufacturer: MediaTek Inc.
usb 1-12: SerialNumber: 000000000
[  ] Compiled boards.jse, pScript = 0x0x10f128d0.
[  ] Executing boards.jse.
[  ] <boards.jse
[  ] CreateNvLinkLibInterface : Creating NvLink library interface NvLinkLibIfUser
[  ] CreateAllDevInterfaces : Created NvLink device interface NvSwitchDevIf
[  ] CreateAllDevInterfaces : Created NvLink device interface NvGpuDevIf
[  ] Warning: Can't find Pci device with class code 0x68000, index 0
[  ] Find NvSwitch ports
[  ] -------Finish NvSwitch detection-----
[  ] NVRM <func>: Unrecognized AMD processor in cpuidInfoAMD
[  ] Physical Graphics controller at 0000:01:00.0
[  ] reg virtual base = 0x7f69017fd000
[  ] IOVA enabled
[  ] Detected 47 sysmem address bits for chip id 0xd06 at 0000:01:00.0, IOVA enabled
[  ] BAR0 base = 0x0_F5000000,
     size = 0x01000000
[  ] BAR1 base = 0x0_A0000000,
     size = 0x10000000
[  ] BAR2 base = 0x0_B0000000,
     size = 0x02000000
[  ] Vendor ID = 0x10DE
[  ] Device ID = 0x2805
[  ] Chip ID   = 0x00000196
[  ] [0000:01:00.0] cap id 0x5 found at offs 0x68
[  ] [0000:01:00.0] cap id 0x11 not found
[  ] mods [1]: set dma mask 47 for dev 0000:01:00.0
[  ] [0000:01:00.0] cap id 0x10 found at offs 0x78
[  ] [0000:01:00.0] extended cap id 0x1e found at offs 0x0258
[  ] Register manual file ad106_ref.txt not found
[  ] Physical Graphics controller at 0000:0d:00.0
[  ] Bypassing non-NVIDIA card
[  ] Warning: Can't find Pci device with class code 0x30000, index 2
[  ] Warning: Can't find Pci device with class code 0x30200, index 0
[  ] Found Test Devices :
[  ]    GPU 0 [01:00.0]
[  ] Find bridge ports
[  ] [0000:00:01.1] bridge sec=01 sub=01 vendor=1022 devid=14da uniq_link_poll=false
[  ] [0000:00:01.2] bridge sec=02 sub=02 vendor=1022 devid=14da uniq_link_poll=false
[  ] [0000:00:02.1] bridge sec=03 sub=0b vendor=1022 devid=14da uniq_link_poll=false
[  ] [0000:00:02.2] bridge sec=0c sub=0c vendor=1022 devid=14da uniq_link_poll=false
[  ] [0000:00:08.1] bridge sec=0d sub=0d vendor=1022 devid=14da uniq_link_poll=false
[  ] [0000:00:08.3] bridge sec=0e sub=0e vendor=1022 devid=14da uniq_link_poll=false
[  ] [0000:03:00.0] bridge sec=04 sub=0b vendor=1022 devid=43f4 uniq_link_poll=false
[  ] [0000:04:00.0] bridge sec=05 sub=05 vendor=1022 devid=43f5 uniq_link_poll=false
[  ] [0000:04:04.0] bridge sec=06 sub=06 vendor=1022 devid=43f5 uniq_link_poll=false
[  ] [0000:04:05.0] bridge sec=07 sub=07 vendor=1022 devid=43f5 uniq_link_poll=false
[  ] [0000:04:07.0] bridge sec=08 sub=08 vendor=1022 devid=43f5 uniq_link_poll=false
[  ] [0000:04:08.0] bridge sec=09 sub=09 vendor=1022 devid=43f5 uniq_link_poll=false
[  ] [0000:04:0c.0] bridge sec=0a sub=0a vendor=1022 devid=43f5 uniq_link_poll=false
[  ] [0000:04:0d.0] bridge sec=0b sub=0b vendor=1022 devid=43f5 uniq_link_poll=false
[  ] Warning: Can't find Pci device with class code 0x60400, index 14
[  ] Warning: Can't find Pci device with class code 0x60401, index 15
[  ] Find siblings at 0000:00:xx.x
[  ]   Sibling found: domain=0000 sec=01 sub=01
[  ]   Sibling found: domain=0000 sec=02 sub=02
[  ]   Sibling found: domain=0000 sec=03 sub=0b
[  ]   Sibling found: domain=0000 sec=0c sub=0c
[  ]   Sibling found: domain=0000 sec=0d sub=0d
[  ]   Sibling found: domain=0000 sec=0e sub=0e
[  ]   Found chipset controller's port at 0000:00:01.1
[  ] [0000:00:01.1] cap id 0x10 found at offs 0x58
[  ] [0000:00:01.1] extended cap id 0x1e found at offs 0x0370
[  ] [0000:00:01.1] extended cap id 0x1 not found
[  ] [0000:00:01.2] cap id 0x10 found at offs 0x58
[  ] [0000:00:01.2] extended cap id 0x1e found at offs 0x0370
[  ] [0000:00:01.2] extended cap id 0x1 not found
[  ] [0000:00:02.1] cap id 0x10 found at offs 0x58
[  ] [0000:00:02.1] extended cap id 0x1e found at offs 0x0370
[  ] [0000:00:02.1] extended cap id 0x1 not found
[  ] [0000:00:02.2] cap id 0x10 found at offs 0x58
[  ] [0000:00:02.2] extended cap id 0x1e found at offs 0x0370
[  ] [0000:00:02.2] extended cap id 0x1 not found
[  ] [0000:00:08.1] cap id 0x10 found at offs 0x58
[  ] [0000:00:08.1] extended cap id 0x1 not found
[  ] [0000:00:08.3] cap id 0x10 found at offs 0x58
[  ] [0000:00:08.3] extended cap id 0x1 not found
[  ] Root check: 0000:00:01.1 IsRoot=true
[  ] Connecting ports for Chipset 0000:00:01.1:
[  ]   DP0 0000:00:01.1 connects to test device GPU 0 [01:00.0]
[  ] ------Finish bridge detection-----
[  ] Detected EFI console in BAR1 of GPU 0 [01:00.0]
[  ] Suspended Linux console
[  ] InitializeAllDevices : RM not initialized, skipping GPU nvlink device initialization
[  ]                  GPU 0 [01:00.0]  dev.sub 0.0
[  ]                  ----------------------------------------
[  ] DevInst        : 0
[  ] PCI Location   : 0x00, 0x01, 0x00, 0x00
[  ] GPU DID        : 0x2805
[  ] PDI            : 0x96a91ae7a68aef3d
[  ] Raw ECID       : 0x010085c000000009024909e1
[  ] Raw ECID (GHS) : 0x1780902490800000017040200
[  ] ECID           : TSMC-U2G992-23_x8_y8
[  ] Device Id      : AD106
[  ] Revision       : a1
[  ] Sub Revision   : 0
[  ] NV Base        : 0xf5000000
[  ] FB Base        : 0xa0000000
[  ] IRQ            : 255
[  ] MSI-X not supported on GPU 0 [01:00.0], skipping
[  ] Detected supported interrupt types: legacy MSI
[  ] mods [1]: enabled dev 0000:01:00.0
[  ] Disabling interrupt tree 0
[  ] IRQ statistics:
[  ]   num IRQs:      10
[  ]   avg IRQ delay: 0us
[  ]   min IRQ delay: 0us
[  ]   max IRQ delay: 0us
[  ] Legacy interrupts verified OK
[  ] Disabling interrupt tree 0
[  ] IRQ statistics:
[  ]   num IRQs:      10
[  ]   avg IRQ delay: 0us
[  ]   min IRQ delay: 0us
[  ]   max IRQ delay: 0us
[  ] MSI verified OK
[  ] Skipping MSI-X verification
[  ] Hooking MSI
[  ] Warning: Can't find Pci device with class code 0x40300, index 3
[  ] AD106 Azalia: DeviceId: 0x22bd.
[  ] Bypassing unsupported vendor: 0x1002Device already uninitialized
[  ] Bypassing unsupported vendor: 0x1022Device already uninitialized
[  ] Found 1 controllers (DevId 127)
[  ] SetAspm on GPU: 0x10840042
[  ] Reset polled 2 times in 1 us on AzaRegWaitPoll and returned 0.
[  ] Reset polled 2 times in 1 us on AzaRegWaitPoll and returned 0.
[  ] mods [1]: set dma mask 47 for dev 0000:01:00.1
[  ] Found codec on sdin 0
[  ] The codec contains 1 function group(s).
[  ] usb 1-11.1: new full-speed USB device number 7 using xhci_hcd
[  ] PEX: set downstream ASPM=0x70840042
[  ] [0000:01:00.0] cap id 0x10 found at offs 0x78
[  ] Failed to get DRAM information from VBIOS NVDM. Will attempt to read from the DRAM.
[  ] Warning: Can't find Pci device with class code 0x30000, index 2
[  ] Warning: Can't find Pci device with class code 0x30200, index 0
[  ] Warning: Can't find Pci device with class code 0x40300, index 3
[  ] Warning: Can't find Pci device with class code 0x60000, index 14
[  ] Warning: Can't find Pci device with class code 0x60100, index 1
[  ] Warning: Can't find Pci device with class code 0x60200, index 0
[  ] Warning: Can't find Pci device with class code 0x60300, index 0
[  ] Warning: Can't find Pci device with class code 0x60400, index 14
[  ] Warning: Can't find Pci device with class code 0x60401, index 0
[  ] Warning: Can't find Pci device with class code 0x60500, index 0
[  ] Warning: Can't find Pci device with class code 0x60600, index 0
[  ] Warning: Can't find Pci device with class code 0x60700, index 0
[  ] Warning: Can't find Pci device with class code 0x60800, index 0
[  ] Warning: Can't find Pci device with class code 0x60940, index 0
[  ] Warning: Can't find Pci device with class code 0x60980, index 0
[  ] Warning: Can't find Pci device with class code 0x60a00, index 0
[  ] Warning: Can't find Pci device with class code 0x60b00, index 0
[  ] Warning: Can't find Pci device with class code 0x60b01, index 0
[  ] Warning: Can't find Pci device with class code 0x68000, index 0
[  ] Setup dma base only supported on PPC, skipping
[  ] ACPI: Unable to evaluate dev method _DSM, id 0xffffffff on 0000:01:00.0
[  ] ACPI: Unable to evaluate dev method _DSM, id 0xffffffff on 0000:01:00.0
[  ] ACPI: Unable to evaluate dev method _DSM, id 0xffffffff on 0000:01:00.0
[  ] ACPI: Unable to evaluate dev method _DSM, id 0xffffffff on 0000:01:00.0
[  ] ACPI: Unable to evaluate dev method _DSM, id 0xffffffff on 0000:01:00.0
[  ] ACPI: Unable to evaluate dev method _DSM, id 0xffffffff on 0000:01:00.0
[  ] Found (0, 0, 20, 0) with cc = 0xc0500, vid = 0x1022, did = 0x790b
[  ] Found AMD KernCZ SMBus Host ControllerFound 1 devices
[  ] AmdSmbPort::Transaction - Device Busy
[  ] EC Device not found on Smbus
[  ] ACPI: Unable to evaluate dev method _PR0, id 0xffffffff on 0000:00:01.1
[  ] mods [1] error: ACPI method _DSM failed
mods [1] error: ACPI method _DSM failed
mods [1] error: ACPI method _DSM failed
mods [1] error: ACPI method _DSM failed
mods [1] error: ACPI method _DSM failed
mods [1] error: ACPI method _DSM failed
mods [1] error: ACPI method _PR0 failed
[  ] usb 1-11.1: New USB device found, idVendor=1d57, idProduct=fa60, bcdDevice=20.05
usb 1-11.1: New USB device strings: Mfr=1, Product=2, SerialNumber=0
usb 1-11.1: Product: 2.4G Mouse
usb 1-11.1: Manufacturer: LXD
[  ] input: LXD 2.4G Mouse as /devices/pci0000:00/0000:00:02.1/0000:03:00.0/0000:04:0c.0/0000:0a:00.0/usb1/1-11/1-11.1/1-11.1:1.0/0003:1D57:FA60.0005/input/input16
[  ] NVRM <func>: OBJVBIOS: Unknown BIT token 0x73! Skipping...
[  ] NVRM <func>: Revlock: VBIOS or RM Revlock level too low.
[  ] NVRM <func>: MinimumRmRevlockLvl: 9
[  ] NVRM <func>: currentRmRevlockLvl: 7
[  ] NVRM <func>: minimumVbiosRevlockLvl: 0
[  ] NVRM <func>: CurrentVbiosRevlockLvl: 0
[  ] NVRM <func>: bp @ <fileid:0x0001f0>:2702
[  ] bp @ <fileid:0x0001f0>:2702
[  ]
[  ] ** ModsDrvBreakPoint on GPU 0 [01:00.0] **

[ 0] -------------------------- END ASSERT INFO DUMP --------------------------
Error 000000000542 : Gpu.Initialize NVRM VBIOS invalid or rejected [0.359 seconds]
Error 000000000542 : Global.PrintGpuInitError NVRM VBIOS invalid or rejected [0.000 seconds]
Error 000000000542 : Global.InitializeGpuTests NVRM VBIOS invalid or rejected [0.374 seconds]

Error Code = 000000000818 (Mods detected an assertion failure)


 #######     ####    ########  ###
 #######    ######   ########  ###
 ##        ##    ##     ##     ###
 ##        ##    ##     ##     ###
 #######   ########     ##     ###
 #######   ########     ##     ###
 ##        ##    ##     ##     ###
 ##        ##    ##  ########  ########
 ##        ##    ##  ########  ########


MODS end  : Thu Jun 19 01:48:12 2025  [1.269 seconds (00:00:01.269 h:m:s)]

mats version 520.112.  Testing AD106 with 10 MB of memory starting with 0 MB.
Memory Errors on
Read    Error Count: 0
Write   Error Count: 256
Unknown Error Count: 0

=== MEMORY ERRORS BY SUBPARTITION ===
SUBPART READ ERRORS WRITE ERRORS UNKNOWN ERRS
------- ----------- ------------ ------------
FBIOA0            0           64            0
FBIOA1            0           64            0
FBIOB0            0           64            0
FBIOB1            0           64            0

Failing Bits:
A000 A001 A002 A003 A004 A005 A006 A007 A008 A009 A010 A011 A012 A013 A014 A015
A016 A017 A018 A019 A020 A021 A022 A023 A024 A025 A026 A027 A028 A029 A030 A031
A032 A033 A034 A035 A036 A037 A038 A039 A040 A041 A042 A043 A044 A045 A046 A047
A048 A049 A050 A051 A052 A053 A054 A055 A056 A057 A058 A059 A060 A061 A062 A063
B000 B001 B002 B003 B004 B005 B006 B007 B008 B009 B010 B011 B012 B013 B014 B015
B016 B017 B018 B019 B020 B021 B022 B023 B024 B025 B026 B027 B028 B029 B030 B031
B032 B033 B034 B035 B036 B037 B038 B039 B040 B041 B042 B043 B044 B045 B046 B047
B048 B049 B050 B051 B052 B053 B054 B055 B056 B057 B058 B059 B060 B061 B062 B063


Memory Errors on
Read    Error Count: 0
Write   Error Count: 256
Unknown Error Count: 0

=== MEMORY ERRORS BY SUBPARTITION ===
SUBPART READ ERRORS WRITE ERRORS UNKNOWN ERRS
------- ----------- ------------ ------------
FBIOA0            0           64            0
FBIOA1            0           64            0
FBIOB0            0           64            0
FBIOB1            0           64            0

Failing Bits:
A000 A001 A002 A003 A004 A005 A006 A007 A008 A009 A010 A011 A012 A013 A014 A015
A016 A017 A018 A019 A020 A021 A022 A023 A024 A025 A026 A027 A028 A029 A030 A031
A032 A033 A034 A035 A036 A037 A038 A039 A040 A041 A042 A043 A044 A045 A046 A047
A048 A049 A050 A051 A052 A053 A054 A055 A056 A057 A058 A059 A060 A061 A062 A063
B000 B001 B002 B003 B004 B005 B006 B007 B008 B009 B010 B011 B012 B013 B014 B015
B016 B017 B018 B019 B020 B021 B022 B023 B024 B025 B026 B027 B028 B029 B030 B031
B032 B033 B034 B035 B036 B037 B038 B039 B040 B041 B042 B043 B044 B045 B046 B047
B048 B049 B050 B051 B052 B053 B054 B055 B056 B057 B058 B059 B060 B061 B062 B063



=== MEMORY ERRORS BY BIT ===
P : Partition (FBIO)
                                            READ 0 READ 1 READ ?
P BIT READ ERRORS WRITE ERRORS UNKNOWN ERRS EXP. 1 EXP. 0 EXP. ?
- --- ----------- ------------ ------------ ------ ------ ------
A 000           0           64            0     64      0      0
A 001           0           32            0     32      0      0
A 002           0           64            0     64      0      0
A 003           0           32            0     32      0      0
A 004           0           64            0     64      0      0
A 005           0           32            0     32      0      0
A 006           0           64            0     64      0      0
A 007           0           32            0     32      0      0
A 008           0           64            0     64      0      0
A 009           0           32            0     32      0      0
A 010           0           64            0     64      0      0
A 011           0           32            0     32      0      0
A 012           0           64            0     64      0      0
A 013           0           32            0     32      0      0
A 014           0           64            0     64      0      0
A 015           0           32            0     32      0      0
A 016           0           64            0     64      0      0
A 017           0           32            0     32      0      0
A 018           0           64            0     64      0      0
A 019           0           32            0     32      0      0
A 020           0           64            0     64      0      0
A 021           0           32            0     32      0      0
A 022           0           64            0     64      0      0
A 023           0           32            0     32      0      0
A 024           0           64            0     64      0      0
A 025           0           32            0     32      0      0
A 026           0           64            0     64      0      0
A 027           0           32            0     32      0      0
A 028           0           64            0     64      0      0
A 029           0           32            0     32      0      0
A 030           0           64            0     64      0      0
A 031           0           32            0     32      0      0
A 032           0           64            0     64      0      0
A 033           0           32            0     16     16      0
A 034           0           64            0     64      0      0
A 035           0           32            0     16     16      0
A 036           0           64            0     64      0      0
A 037           0           32            0     16     16      0
A 038           0           64            0     64      0      0
A 039           0           32            0     16     16      0
A 040           0           64            0     64      0      0
A 041           0           32            0     24      8      0
A 042           0           64            0     64      0      0
A 043           0           32            0     24      8      0
A 044           0           64            0     64      0      0
A 045           0           32            0     24      8      0
A 046           0           64            0     64      0      0
A 047           0           32            0     24      8      0
A 048           0           64            0     64      0      0
A 049           0           32            0     32      0      0
A 050           0           64            0     64      0      0
A 051           0           32            0     32      0      0
A 052           0           64            0     64      0      0
A 053           0           32            0     32      0      0
A 054           0           64            0     64      0      0
A 055           0           32            0     32      0      0
A 056           0           64            0     64      0      0
A 057           0           32            0     32      0      0
A 058           0           64            0     64      0      0
A 059           0           32            0     32      0      0
A 060           0           64            0     64      0      0
A 061           0           32            0     32      0      0
A 062           0           64            0     64      0      0
A 063           0           32            0     32      0      0
B 000           0           64            0     64      0      0
B 001           0           32            0     32      0      0
B 002           0           64            0     64      0      0
B 003           0           32            0     32      0      0
B 004           0           64            0     64      0      0
B 005           0           32            0     32      0      0
B 006           0           64            0     64      0      0
B 007           0           32            0     32      0      0
B 008           0           64            0     64      0      0
B 009           0           32            0     32      0      0
B 010           0           64            0     64      0      0
B 011           0           32            0     32      0      0
B 012           0           64            0     64      0      0
B 013           0           32            0     32      0      0
B 014           0           64            0     64      0      0
B 015           0           32            0     32      0      0
B 016           0           64            0     64      0      0
B 017           0           32            0     32      0      0
B 018           0           64            0     64      0      0
B 019           0           32            0     32      0      0
B 020           0           64            0     64      0      0
B 021           0           32            0     32      0      0
B 022           0           64            0     64      0      0
B 023           0           32            0     32      0      0
B 024           0           64            0     64      0      0
B 025           0           32            0     32      0      0
B 026           0           64            0     64      0      0
B 027           0           32            0     32      0      0
B 028           0           64            0     64      0      0
B 029           0           32            0     32      0      0
B 030           0           64            0     64      0      0
B 031           0           32            0     32      0      0
B 032           0           64            0     64      0      0
B 033           0           32            0     16     16      0
B 034           0           64            0     64      0      0
B 035           0           32            0     16     16      0
B 036           0           64            0     64      0      0
B 037           0           32            0     16     16      0
B 038           0           64            0     64      0      0
B 039           0           32            0     16     16      0
B 040           0           64            0     64      0      0
B 041           0           32            0     24      8      0
B 042           0           64            0     64      0      0
B 043           0           32            0     24      8      0
B 044           0           64            0     64      0      0
B 045           0           32            0     24      8      0
B 046           0           64            0     64      0      0
B 047           0           32            0     24      8      0
B 048           0           64            0     64      0      0
B 049           0           32            0     32      0      0
B 050           0           64            0     64      0      0
B 051           0           32            0     32      0      0
B 052           0           64            0     64      0      0
B 053           0           32            0     32      0      0
B 054           0           64            0     64      0      0
B 055           0           32            0     32      0      0
B 056           0           64            0     64      0      0
B 057           0           32            0     32      0      0
B 058           0           64            0     64      0      0
B 059           0           32            0     32      0      0
B 060           0           64            0     64      0      0
B 061           0           32            0     32      0      0
B 062           0           64            0     64      0      0
B 063           0           32            0     32      0      0


=== MEMORY ERRORS BY ADDRESS ===
ADDRESS : Failing memory address, or buffer offset if starting with 'X+'
T : Type of memory error: W = write, R = read
P : Partition (FBIO)
S : Subpartition
B : Bank
E : Beat
U : PseudoChannel
   ADDRESS EXPECTED   ACTUAL  REREAD1  REREAD2 FAILBITS TPSBEU SLICE  ROW COL                                                                          BIT(s)
   ------- --------   ------  -------  ------- -------- ------ -----  --- ---                                                                          ------
0000840000 ffffffff 00000000 00000000 00000000 ffffffff WA1201     1 0010 040 A048,A049,A050,A051,A052,A053,A054,A055,A056,A057,A058,A059,A060,A061,A062,A063
0000840004 ffffffff 00000000 00000000 00000000 ffffffff WA1221     1 0010 040 A048,A049,A050,A051,A052,A053,A054,A055,A056,A057,A058,A059,A060,A061,A062,A063
0000840008 ffffffff 00000000 00000000 00000000 ffffffff WA1241     1 0010 040 A048,A049,A050,A051,A052,A053,A054,A055,A056,A057,A058,A059,A060,A061,A062,A063
000084000c ffffffff 00000000 00000000 00000000 ffffffff WA1261     1 0010 040 A048,A049,A050,A051,A052,A053,A054,A055,A056,A057,A058,A059,A060,A061,A062,A063
0000840010 ffffffff 00000000 00000000 00000000 ffffffff WA1281     1 0010 040 A048,A049,A050,A051,A052,A053,A054,A055,A056,A057,A058,A059,A060,A061,A062,A063
0000840014 ffffffff 00000000 00000000 00000000 ffffffff WA12a1     1 0010 040 A048,A049,A050,A051,A052,A053,A054,A055,A056,A057,A058,A059,A060,A061,A062,A063
0000840018 ffffffff 00000000 00000000 00000000 ffffffff WA12c1     1 0010 040 A048,A049,A050,A051,A052,A053,A054,A055,A056,A057,A058,A059,A060,A061,A062,A063
000084001c ffffffff 00000000 00000000 00000000 ffffffff WA12e1     1 0010 040 A048,A049,A050,A051,A052,A053,A054,A055,A056,A057,A058,A059,A060,A061,A062,A063
0000842000 ffffffff 00000000 00000000 00000000 ffffffff WB1601     3 0010 050 B048,B049,B050,B051,B052,B053,B054,B055,B056,B057,B058,B059,B060,B061,B062,B063
0000842004 ffffffff 00000000 00000000 00000000 ffffffff WB1621     3 0010 050 B048,B049,B050,B051,B052,B053,B054,B055,B056,B057,B058,B059,B060,B061,B062,B063
0000842008 ffffffff 00000000 00000000 00000000 ffffffff WB1641     3 0010 050 B048,B049,B050,B051,B052,B053,B054,B055,B056,B057,B058,B059,B060,B061,B062,B063
000084200c ffffffff 00000000 00000000 00000000 ffffffff WB1661     3 0010 050 B048,B049,B050,B051,B052,B053,B054,B055,B056,B057,B058,B059,B060,B061,B062,B063
0000842010 ffffffff 00000000 00000000 00000000 ffffffff WB1681     3 0010 050 B048,B049,B050,B051,B052,B053,B054,B055,B056,B057,B058,B059,B060,B061,B062,B063
0000842014 ffffffff 00000000 00000000 00000000 ffffffff WB16a1     3 0010 050 B048,B049,B050,B051,B052,B053,B054,B055,B056,B057,B058,B059,B060,B061,B062,B063
0000842018 ffffffff 00000000 00000000 00000000 ffffffff WB16c1     3 0010 050 B048,B049,B050,B051,B052,B053,B054,B055,B056,B057,B058,B059,B060,B061,B062,B063
000084201c ffffffff 00000000 00000000 00000000 ffffffff WB16e1     3 0010 050 B048,B049,B050,B051,B052,B053,B054,B055,B056,B057,B058,B059,B060,B061,B062,B063
0000844000 ffffffff 00000000 00000000 00000000 ffffffff WA1200     2 0010 050 A032,A033,A034,A035,A036,A037,A038,A039,A040,A041,A042,A043,A044,A045,A046,A047
0000844004 ffffffff 00000000 00000000 00000000 ffffffff WA1220     2 0010 050 A032,A033,A034,A035,A036,A037,A038,A039,A040,A041,A042,A043,A044,A045,A046,A047
0000844008 ffffffff 00000000 00000000 00000000 ffffffff WA1240     2 0010 050 A032,A033,A034,A035,A036,A037,A038,A039,A040,A041,A042,A043,A044,A045,A046,A047
000084400c ffffffff 00000000 00000000 00000000 ffffffff WA1260     2 0010 050 A032,A033,A034,A035,A036,A037,A038,A039,A040,A041,A042,A043,A044,A045,A046,A047
0000844010 ffffffff 00000000 00000000 00000000 ffffffff WA1280     2 0010 050 A032,A033,A034,A035,A036,A037,A038,A039,A040,A041,A042,A043,A044,A045,A046,A047
0000844014 ffffffff 00000000 00000000 00000000 ffffffff WA12a0     2 0010 050 A032,A033,A034,A035,A036,A037,A038,A039,A040,A041,A042,A043,A044,A045,A046,A047
0000844018 ffffffff 00000000 00000000 00000000 ffffffff WA12c0     2 0010 050 A032,A033,A034,A035,A036,A037,A038,A039,A040,A041,A042,A043,A044,A045,A046,A047
000084401c ffffffff 00000000 00000000 00000000 ffffffff WA12e0     2 0010 050 A032,A033,A034,A035,A036,A037,A038,A039,A040,A041,A042,A043,A044,A045,A046,A047
0000846000 ffffffff 00000000 00000000 00000000 ffffffff WB1600     0 0010 040 B032,B033,B034,B035,B036,B037,B038,B039,B040,B041,B042,B043,B044,B045,B046,B047
0000846004 ffffffff 00000000 00000000 00000000 ffffffff WB1620     0 0010 040 B032,B033,B034,B035,B036,B037,B038,B039,B040,B041,B042,B043,B044,B045,B046,B047
0000846008 ffffffff 00000000 00000000 00000000 ffffffff WB1640     0 0010 040 B032,B033,B034,B035,B036,B037,B038,B039,B040,B041,B042,B043,B044,B045,B046,B047
000084600c ffffffff 00000000 00000000 00000000 ffffffff WB1660     0 0010 040 B032,B033,B034,B035,B036,B037,B038,B039,B040,B041,B042,B043,B044,B045,B046,B047
0000846010 ffffffff 00000000 00000000 00000000 ffffffff WB1680     0 0010 040 B032,B033,B034,B035,B036,B037,B038,B039,B040,B041,B042,B043,B044,B045,B046,B047
0000846014 ffffffff 00000000 00000000 00000000 ffffffff WB16a0     0 0010 040 B032,B033,B034,B035,B036,B037,B038,B039,B040,B041,B042,B043,B044,B045,B046,B047
0000846018 ffffffff 00000000 00000000 00000000 ffffffff WB16c0     0 0010 040 B032,B033,B034,B035,B036,B037,B038,B039,B040,B041,B042,B043,B044,B045,B046,B047
000084601c ffffffff 00000000 00000000 00000000 ffffffff WB16e0     0 0010 040 B032,B033,B034,B035,B036,B037,B038,B039,B040,B041,B042,B043,B044,B045,B046,B047
0000848000 ffffffff 00000000 00000000 00000000 ffffffff WA0a00     0 0010 040 A000,A001,A002,A003,A004,A005,A006,A007,A008,A009,A010,A011,A012,A013,A014,A015
0000848004 ffffffff 00000000 00000000 00000000 ffffffff WA0a20     0 0010 040 A000,A001,A002,A003,A004,A005,A006,A007,A008,A009,A010,A011,A012,A013,A014,A015
0000848008 ffffffff 00000000 00000000 00000000 ffffffff WA0a40     0 0010 040 A000,A001,A002,A003,A004,A005,A006,A007,A008,A009,A010,A011,A012,A013,A014,A015
000084800c ffffffff 00000000 00000000 00000000 ffffffff WA0a60     0 0010 040 A000,A001,A002,A003,A004,A005,A006,A007,A008,A009,A010,A011,A012,A013,A014,A015
0000848010 ffffffff 00000000 00000000 00000000 ffffffff WA0a80     0 0010 040 A000,A001,A002,A003,A004,A005,A006,A007,A008,A009,A010,A011,A012,A013,A014,A015
0000848014 ffffffff 00000000 00000000 00000000 ffffffff WA0aa0     0 0010 040 A000,A001,A002,A003,A004,A005,A006,A007,A008,A009,A010,A011,A012,A013,A014,A015
0000848018 ffffffff 00000000 00000000 00000000 ffffffff WA0ac0     0 0010 040 A000,A001,A002,A003,A004,A005,A006,A007,A008,A009,A010,A011,A012,A013,A014,A015
000084801c ffffffff 00000000 00000000 00000000 ffffffff WA0ae0     0 0010 040 A000,A001,A002,A003,A004,A005,A006,A007,A008,A009,A010,A011,A012,A013,A014,A015
000084a000 ffffffff 00000000 00000000 00000000 ffffffff WB0e00     2 0010 050 B000,B001,B002,B003,B004,B005,B006,B007,B008,B009,B010,B011,B012,B013,B014,B015
000084a004 ffffffff 00000000 00000000 00000000 ffffffff WB0e20     2 0010 050 B000,B001,B002,B003,B004,B005,B006,B007,B008,B009,B010,B011,B012,B013,B014,B015
000084a008 ffffffff 00000000 00000000 00000000 ffffffff WB0e40     2 0010 050 B000,B001,B002,B003,B004,B005,B006,B007,B008,B009,B010,B011,B012,B013,B014,B015
000084a00c ffffffff 00000000 00000000 00000000 ffffffff WB0e60     2 0010 050 B000,B001,B002,B003,B004,B005,B006,B007,B008,B009,B010,B011,B012,B013,B014,B015
000084a010 ffffffff 00000000 00000000 00000000 ffffffff WB0e80     2 0010 050 B000,B001,B002,B003,B004,B005,B006,B007,B008,B009,B010,B011,B012,B013,B014,B015
000084a014 ffffffff 00000000 00000000 00000000 ffffffff WB0ea0     2 0010 050 B000,B001,B002,B003,B004,B005,B006,B007,B008,B009,B010,B011,B012,B013,B014,B015
000084a018 ffffffff 00000000 00000000 00000000 ffffffff WB0ec0     2 0010 050 B000,B001,B002,B003,B004,B005,B006,B007,B008,B009,B010,B011,B012,B013,B014,B015
000084a01c ffffffff 00000000 00000000 00000000 ffffffff WB0ee0     2 0010 050 B000,B001,B002,B003,B004,B005,B006,B007,B008,B009,B010,B011,B012,B013,B014,B015
000084c000 ffffffff 00000000 00000000 00000000 ffffffff WA0a01     3 0010 050 A016,A017,A018,A019,A020,A021,A022,A023,A024,A025,A026,A027,A028,A029,A030,A031
000084c004 ffffffff 00000000 00000000 00000000 ffffffff WA0a21     3 0010 050 A016,A017,A018,A019,A020,A021,A022,A023,A024,A025,A026,A027,A028,A029,A030,A031
000084c008 ffffffff 00000000 00000000 00000000 ffffffff WA0a41     3 0010 050 A016,A017,A018,A019,A020,A021,A022,A023,A024,A025,A026,A027,A028,A029,A030,A031
000084c00c ffffffff 00000000 00000000 00000000 ffffffff WA0a61     3 0010 050 A016,A017,A018,A019,A020,A021,A022,A023,A024,A025,A026,A027,A028,A029,A030,A031
000084c010 ffffffff 00000000 00000000 00000000 ffffffff WA0a81     3 0010 050 A016,A017,A018,A019,A020,A021,A022,A023,A024,A025,A026,A027,A028,A029,A030,A031
000084c014 ffffffff 00000000 00000000 00000000 ffffffff WA0aa1     3 0010 050 A016,A017,A018,A019,A020,A021,A022,A023,A024,A025,A026,A027,A028,A029,A030,A031
000084c018 ffffffff 00000000 00000000 00000000 ffffffff WA0ac1     3 0010 050 A016,A017,A018,A019,A020,A021,A022,A023,A024,A025,A026,A027,A028,A029,A030,A031
000084c01c ffffffff 00000000 00000000 00000000 ffffffff WA0ae1     3 0010 050 A016,A017,A018,A019,A020,A021,A022,A023,A024,A025,A026,A027,A028,A029,A030,A031
000084e000 ffffffff 00000000 00000000 00000000 ffffffff WB0e01     1 0010 040 B016,B017,B018,B019,B020,B021,B022,B023,B024,B025,B026,B027,B028,B029,B030,B031
000084e004 ffffffff 00000000 00000000 00000000 ffffffff WB0e21     1 0010 040 B016,B017,B018,B019,B020,B021,B022,B023,B024,B025,B026,B027,B028,B029,B030,B031
000084e008 ffffffff 00000000 00000000 00000000 ffffffff WB0e41     1 0010 040 B016,B017,B018,B019,B020,B021,B022,B023,B024,B025,B026,B027,B028,B029,B030,B031
000084e00c ffffffff 00000000 00000000 00000000 ffffffff WB0e61     1 0010 040 B016,B017,B018,B019,B020,B021,B022,B023,B024,B025,B026,B027,B028,B029,B030,B031
000084e010 ffffffff 00000000 00000000 00000000 ffffffff WB0e81     1 0010 040 B016,B017,B018,B019,B020,B021,B022,B023,B024,B025,B026,B027,B028,B029,B030,B031
000084e014 ffffffff 00000000 00000000 00000000 ffffffff WB0ea1     1 0010 040 B016,B017,B018,B019,B020,B021,B022,B023,B024,B025,B026,B027,B028,B029,B030,B031
000084e018 ffffffff 00000000 00000000 00000000 ffffffff WB0ec1     1 0010 040 B016,B017,B018,B019,B020,B021,B022,B023,B024,B025,B026,B027,B028,B029,B030,B031
000084e01c ffffffff 00000000 00000000 00000000 ffffffff WB0ee1     1 0010 040 B016,B017,B018,B019,B020,B021,B022,B023,B024,B025,B026,B027,B028,B029,B030,B031
0000850000 ffffffff 00000000 00000000 00000000 ffffffff WB0700     0 0010 040 B000,B001,B002,B003,B004,B005,B006,B007,B008,B009,B010,B011,B012,B013,B014,B015
0000850004 ffffffff 00000000 00000000 00000000 ffffffff WB0720     0 0010 040 B000,B001,B002,B003,B004,B005,B006,B007,B008,B009,B010,B011,B012,B013,B014,B015
0000850008 ffffffff 00000000 00000000 00000000 ffffffff WB0740     0 0010 040 B000,B001,B002,B003,B004,B005,B006,B007,B008,B009,B010,B011,B012,B013,B014,B015
000085000c ffffffff 00000000 00000000 00000000 ffffffff WB0760     0 0010 040 B000,B001,B002,B003,B004,B005,B006,B007,B008,B009,B010,B011,B012,B013,B014,B015
0000850010 ffffffff 00000000 00000000 00000000 ffffffff WB0780     0 0010 040 B000,B001,B002,B003,B004,B005,B006,B007,B008,B009,B010,B011,B012,B013,B014,B015
0000850014 ffffffff 00000000 00000000 00000000 ffffffff WB07a0     0 0010 040 B000,B001,B002,B003,B004,B005,B006,B007,B008,B009,B010,B011,B012,B013,B014,B015
0000850018 ffffffff 00000000 00000000 00000000 ffffffff WB07c0     0 0010 040 B000,B001,B002,B003,B004,B005,B006,B007,B008,B009,B010,B011,B012,B013,B014,B015
000085001c ffffffff 00000000 00000000 00000000 ffffffff WB07e0     0 0010 040 B000,B001,B002,B003,B004,B005,B006,B007,B008,B009,B010,B011,B012,B013,B014,B015
0000852000 ffffffff 00000000 00000000 00000000 ffffffff WA0300     2 0010 050 A000,A001,A002,A003,A004,A005,A006,A007,A008,A009,A010,A011,A012,A013,A014,A015
0000852004 ffffffff 00000000 00000000 00000000 ffffffff WA0320     2 0010 050 A000,A001,A002,A003,A004,A005,A006,A007,A008,A009,A010,A011,A012,A013,A014,A015
0000852008 ffffffff 00000000 00000000 00000000 ffffffff WA0340     2 0010 050 A000,A001,A002,A003,A004,A005,A006,A007,A008,A009,A010,A011,A012,A013,A014,A015
000085200c ffffffff 00000000 00000000 00000000 ffffffff WA0360     2 0010 050 A000,A001,A002,A003,A004,A005,A006,A007,A008,A009,A010,A011,A012,A013,A014,A015
0000852010 ffffffff 00000000 00000000 00000000 ffffffff WA0380     2 0010 050 A000,A001,A002,A003,A004,A005,A006,A007,A008,A009,A010,A011,A012,A013,A014,A015
0000852014 ffffffff 00000000 00000000 00000000 ffffffff WA03a0     2 0010 050 A000,A001,A002,A003,A004,A005,A006,A007,A008,A009,A010,A011,A012,A013,A014,A015
0000852018 ffffffff 00000000 00000000 00000000 ffffffff WA03c0     2 0010 050 A000,A001,A002,A003,A004,A005,A006,A007,A008,A009,A010,A011,A012,A013,A014,A015
000085201c ffffffff 00000000 00000000 00000000 ffffffff WA03e0     2 0010 050 A000,A001,A002,A003,A004,A005,A006,A007,A008,A009,A010,A011,A012,A013,A014,A015
0000854000 ffffffff 00000000 00000000 00000000 ffffffff WB0701     3 0010 050 B016,B017,B018,B019,B020,B021,B022,B023,B024,B025,B026,B027,B028,B029,B030,B031
0000854004 ffffffff 00000000 00000000 00000000 ffffffff WB0721     3 0010 050 B016,B017,B018,B019,B020,B021,B022,B023,B024,B025,B026,B027,B028,B029,B030,B031
0000854008 ffffffff 00000000 00000000 00000000 ffffffff WB0741     3 0010 050 B016,B017,B018,B019,B020,B021,B022,B023,B024,B025,B026,B027,B028,B029,B030,B031
000085400c ffffffff 00000000 00000000 00000000 ffffffff WB0761     3 0010 050 B016,B017,B018,B019,B020,B021,B022,B023,B024,B025,B026,B027,B028,B029,B030,B031
0000854010 ffffffff 00000000 00000000 00000000 ffffffff WB0781     3 0010 050 B016,B017,B018,B019,B020,B021,B022,B023,B024,B025,B026,B027,B028,B029,B030,B031
0000854014 ffffffff 00000000 00000000 00000000 ffffffff WB07a1     3 0010 050 B016,B017,B018,B019,B020,B021,B022,B023,B024,B025,B026,B027,B028,B029,B030,B031
0000854018 ffffffff 00000000 00000000 00000000 ffffffff WB07c1     3 0010 050 B016,B017,B018,B019,B020,B021,B022,B023,B024,B025,B026,B027,B028,B029,B030,B031
000085401c ffffffff 00000000 00000000 00000000 ffffffff WB07e1     3 0010 050 B016,B017,B018,B019,B020,B021,B022,B023,B024,B025,B026,B027,B028,B029,B030,B031
0000856000 ffffffff 00000000 00000000 00000000 ffffffff WA0301     1 0010 040 A016,A017,A018,A019,A020,A021,A022,A023,A024,A025,A026,A027,A028,A029,A030,A031
0000856004 ffffffff 00000000 00000000 00000000 ffffffff WA0321     1 0010 040 A016,A017,A018,A019,A020,A021,A022,A023,A024,A025,A026,A027,A028,A029,A030,A031
0000856008 ffffffff 00000000 00000000 00000000 ffffffff WA0341     1 0010 040 A016,A017,A018,A019,A020,A021,A022,A023,A024,A025,A026,A027,A028,A029,A030,A031
000085600c ffffffff 00000000 00000000 00000000 ffffffff WA0361     1 0010 040 A016,A017,A018,A019,A020,A021,A022,A023,A024,A025,A026,A027,A028,A029,A030,A031
0000856010 ffffffff 00000000 00000000 00000000 ffffffff WA0381     1 0010 040 A016,A017,A018,A019,A020,A021,A022,A023,A024,A025,A026,A027,A028,A029,A030,A031
0000856014 ffffffff 00000000 00000000 00000000 ffffffff WA03a1     1 0010 040 A016,A017,A018,A019,A020,A021,A022,A023,A024,A025,A026,A027,A028,A029,A030,A031
0000856018 ffffffff 00000000 00000000 00000000 ffffffff WA03c1     1 0010 040 A016,A017,A018,A019,A020,A021,A022,A023,A024,A025,A026,A027,A028,A029,A030,A031
000085601c ffffffff 00000000 00000000 00000000 ffffffff WA03e1     1 0010 040 A016,A017,A018,A019,A020,A021,A022,A023,A024,A025,A026,A027,A028,A029,A030,A031
0000858000 ffffffff 00000000 00000000 00000000 ffffffff WB1f01     1 0010 040 B048,B049,B050,B051,B052,B053,B054,B055,B056,B057,B058,B059,B060,B061,B062,B063
0000858004 ffffffff 00000000 00000000 00000000 ffffffff WB1f21     1 0010 040 B048,B049,B050,B051,B052,B053,B054,B055,B056,B057,B058,B059,B060,B061,B062,B063
0000858008 ffffffff 00000000 00000000 00000000 ffffffff WB1f41     1 0010 040 B048,B049,B050,B051,B052,B053,B054,B055,B056,B057,B058,B059,B060,B061,B062,B063
000085800c ffffffff 00000000 00000000 00000000 ffffffff WB1f61     1 0010 040 B048,B049,B050,B051,B052,B053,B054,B055,B056,B057,B058,B059,B060,B061,B062,B063
0000858010 ffffffff 00000000 00000000 00000000 ffffffff WB1f81     1 0010 040 B048,B049,B050,B051,B052,B053,B054,B055,B056,B057,B058,B059,B060,B061,B062,B063
0000858014 ffffffff 00000000 00000000 00000000 ffffffff WB1fa1     1 0010 040 B048,B049,B050,B051,B052,B053,B054,B055,B056,B057,B058,B059,B060,B061,B062,B063
0000858018 ffffffff 00000000 00000000 00000000 ffffffff WB1fc1     1 0010 040 B048,B049,B050,B051,B052,B053,B054,B055,B056,B057,B058,B059,B060,B061,B062,B063
000085801c ffffffff 00000000 00000000 00000000 ffffffff WB1fe1     1 0010 040 B048,B049,B050,B051,B052,B053,B054,B055,B056,B057,B058,B059,B060,B061,B062,B063
000085a000 ffffffff 00000000 00000000 00000000 ffffffff WA1b01     3 0010 050 A048,A049,A050,A051,A052,A053,A054,A055,A056,A057,A058,A059,A060,A061,A062,A063
000085a004 ffffffff 00000000 00000000 00000000 ffffffff WA1b21     3 0010 050 A048,A049,A050,A051,A052,A053,A054,A055,A056,A057,A058,A059,A060,A061,A062,A063
000085a008 ffffffff 00000000 00000000 00000000 ffffffff WA1b41     3 0010 050 A048,A049,A050,A051,A052,A053,A054,A055,A056,A057,A058,A059,A060,A061,A062,A063
000085a00c ffffffff 00000000 00000000 00000000 ffffffff WA1b61     3 0010 050 A048,A049,A050,A051,A052,A053,A054,A055,A056,A057,A058,A059,A060,A061,A062,A063
000085a010 ffffffff 00000000 00000000 00000000 ffffffff WA1b81     3 0010 050 A048,A049,A050,A051,A052,A053,A054,A055,A056,A057,A058,A059,A060,A061,A062,A063
000085a014 ffffffff 00000000 00000000 00000000 ffffffff WA1ba1     3 0010 050 A048,A049,A050,A051,A052,A053,A054,A055,A056,A057,A058,A059,A060,A061,A062,A063
000085a018 ffffffff 00000000 00000000 00000000 ffffffff WA1bc1     3 0010 050 A048,A049,A050,A051,A052,A053,A054,A055,A056,A057,A058,A059,A060,A061,A062,A063
000085a01c ffffffff 00000000 00000000 00000000 ffffffff WA1be1     3 0010 050 A048,A049,A050,A051,A052,A053,A054,A055,A056,A057,A058,A059,A060,A061,A062,A063
000085c000 ffffffff 00aaaaaa 00aaaaaa 00aaaaaa ff555555 WB1f00     2 0010 050                     B032,B034,B036,B038,B040,B041,B042,B043,B044,B045,B046,B047
000085c004 ffffffff 00aaaaaa 00aaaaaa 00aaaaaa ff555555 WB1f20     2 0010 050                     B032,B034,B036,B038,B040,B041,B042,B043,B044,B045,B046,B047
000085c008 ffffffff 00aaaaaa 00aaaaaa 00aaaaaa ff555555 WB1f40     2 0010 050                     B032,B034,B036,B038,B040,B041,B042,B043,B044,B045,B046,B047
000085c00c ffffffff 00aaaaaa 00aaaaaa 00aaaaaa ff555555 WB1f60     2 0010 050                     B032,B034,B036,B038,B040,B041,B042,B043,B044,B045,B046,B047
000085c010 ffffffff 00aaaaaa 00aaaaaa 00aaaaaa ff555555 WB1f80     2 0010 050                     B032,B034,B036,B038,B040,B041,B042,B043,B044,B045,B046,B047
000085c014 ffffffff 00aaaaaa 00aaaaaa 00aaaaaa ff555555 WB1fa0     2 0010 050                     B032,B034,B036,B038,B040,B041,B042,B043,B044,B045,B046,B047
000085c018 ffffffff 00aaaaaa 00aaaaaa 00aaaaaa ff555555 WB1fc0     2 0010 050                     B032,B034,B036,B038,B040,B041,B042,B043,B044,B045,B046,B047
000085c01c ffffffff 00aaaaaa 00aaaaaa 00aaaaaa ff555555 WB1fe0     2 0010 050                     B032,B034,B036,B038,B040,B041,B042,B043,B044,B045,B046,B047
000085e000 ffffffff 00aaaaaa 00aaaaaa 00aaaaaa ff555555 WA1b00     0 0010 040                     A032,A034,A036,A038,A040,A041,A042,A043,A044,A045,A046,A047
000085e004 ffffffff 00aaaaaa 00aaaaaa 00aaaaaa ff555555 WA1b20     0 0010 040                     A032,A034,A036,A038,A040,A041,A042,A043,A044,A045,A046,A047
000085e008 ffffffff 00aaaaaa 00aaaaaa 00aaaaaa ff555555 WA1b40     0 0010 040                     A032,A034,A036,A038,A040,A041,A042,A043,A044,A045,A046,A047
000085e00c ffffffff 00aaaaaa 00aaaaaa 00aaaaaa ff555555 WA1b60     0 0010 040                     A032,A034,A036,A038,A040,A041,A042,A043,A044,A045,A046,A047
000085e010 ffffffff 00aaaaaa 00aaaaaa 00aaaaaa ff555555 WA1b80     0 0010 040                     A032,A034,A036,A038,A040,A041,A042,A043,A044,A045,A046,A047
000085e014 ffffffff 00aaaaaa 00aaaaaa 00aaaaaa ff555555 WA1ba0     0 0010 040                     A032,A034,A036,A038,A040,A041,A042,A043,A044,A045,A046,A047
000085e018 ffffffff 00aaaaaa 00aaaaaa 00aaaaaa ff555555 WA1bc0     0 0010 040                     A032,A034,A036,A038,A040,A041,A042,A043,A044,A045,A046,A047
000085e01c ffffffff 00aaaaaa 00aaaaaa 00aaaaaa ff555555 WA1be0     0 0010 040                     A032,A034,A036,A038,A040,A041,A042,A043,A044,A045,A046,A047
000084e01c 55555555 00000000 00000000 00000000 55555555 WB0ee1     1 0010 040                                         B016,B018,B020,B022,B024,B026,B028,B030
000084e018 55555555 00000000 00000000 00000000 55555555 WB0ec1     1 0010 040                                         B016,B018,B020,B022,B024,B026,B028,B030
000084e014 55555555 00000000 00000000 00000000 55555555 WB0ea1     1 0010 040                                         B016,B018,B020,B022,B024,B026,B028,B030
000084e010 55555555 00000000 00000000 00000000 55555555 WB0e81     1 0010 040                                         B016,B018,B020,B022,B024,B026,B028,B030
000084e00c 55555555 00000000 00000000 00000000 55555555 WB0e61     1 0010 040                                         B016,B018,B020,B022,B024,B026,B028,B030
000084e008 55555555 00000000 00000000 00000000 55555555 WB0e41     1 0010 040                                         B016,B018,B020,B022,B024,B026,B028,B030
000084e004 55555555 00000000 00000000 00000000 55555555 WB0e21     1 0010 040                                         B016,B018,B020,B022,B024,B026,B028,B030
000084e000 55555555 00000000 00000000 00000000 55555555 WB0e01     1 0010 040                                         B016,B018,B020,B022,B024,B026,B028,B030
000084c01c 55555555 00000000 00000000 00000000 55555555 WA0ae1     3 0010 050                                         A016,A018,A020,A022,A024,A026,A028,A030
000084c018 55555555 00000000 00000000 00000000 55555555 WA0ac1     3 0010 050                                         A016,A018,A020,A022,A024,A026,A028,A030
000084c014 55555555 00000000 00000000 00000000 55555555 WA0aa1     3 0010 050                                         A016,A018,A020,A022,A024,A026,A028,A030
000084c010 55555555 00000000 00000000 00000000 55555555 WA0a81     3 0010 050                                         A016,A018,A020,A022,A024,A026,A028,A030
000084c00c 55555555 00000000 00000000 00000000 55555555 WA0a61     3 0010 050                                         A016,A018,A020,A022,A024,A026,A028,A030
000084c008 55555555 00000000 00000000 00000000 55555555 WA0a41     3 0010 050                                         A016,A018,A020,A022,A024,A026,A028,A030
000084c004 55555555 00000000 00000000 00000000 55555555 WA0a21     3 0010 050                                         A016,A018,A020,A022,A024,A026,A028,A030
000084c000 55555555 00000000 00000000 00000000 55555555 WA0a01     3 0010 050                                         A016,A018,A020,A022,A024,A026,A028,A030
000084a01c 55555555 00000000 00000000 00000000 55555555 WB0ee0     2 0010 050                                         B000,B002,B004,B006,B008,B010,B012,B014
000084a018 55555555 00000000 00000000 00000000 55555555 WB0ec0     2 0010 050                                         B000,B002,B004,B006,B008,B010,B012,B014
000084a014 55555555 00000000 00000000 00000000 55555555 WB0ea0     2 0010 050                                         B000,B002,B004,B006,B008,B010,B012,B014
000084a010 55555555 00000000 00000000 00000000 55555555 WB0e80     2 0010 050                                         B000,B002,B004,B006,B008,B010,B012,B014
000084a00c 55555555 00000000 00000000 00000000 55555555 WB0e60     2 0010 050                                         B000,B002,B004,B006,B008,B010,B012,B014
000084a008 55555555 00000000 00000000 00000000 55555555 WB0e40     2 0010 050                                         B000,B002,B004,B006,B008,B010,B012,B014
000084a004 55555555 00000000 00000000 00000000 55555555 WB0e20     2 0010 050                                         B000,B002,B004,B006,B008,B010,B012,B014
000084a000 55555555 00000000 00000000 00000000 55555555 WB0e00     2 0010 050                                         B000,B002,B004,B006,B008,B010,B012,B014
000084801c 55555555 00000000 00000000 00000000 55555555 WA0ae0     0 0010 040                                         A000,A002,A004,A006,A008,A010,A012,A014
0000848018 55555555 00000000 00000000 00000000 55555555 WA0ac0     0 0010 040                                         A000,A002,A004,A006,A008,A010,A012,A014
0000848014 55555555 00000000 00000000 00000000 55555555 WA0aa0     0 0010 040                                         A000,A002,A004,A006,A008,A010,A012,A014
0000848010 55555555 00000000 00000000 00000000 55555555 WA0a80     0 0010 040                                         A000,A002,A004,A006,A008,A010,A012,A014
000084800c 55555555 00000000 00000000 00000000 55555555 WA0a60     0 0010 040                                         A000,A002,A004,A006,A008,A010,A012,A014
0000848008 55555555 00000000 00000000 00000000 55555555 WA0a40     0 0010 040                                         A000,A002,A004,A006,A008,A010,A012,A014
0000848004 55555555 00000000 00000000 00000000 55555555 WA0a20     0 0010 040                                         A000,A002,A004,A006,A008,A010,A012,A014
0000848000 55555555 00000000 00000000 00000000 55555555 WA0a00     0 0010 040                                         A000,A002,A004,A006,A008,A010,A012,A014
000084601c 55555555 00000000 00000000 00000000 55555555 WB16e0     0 0010 040                                         B032,B034,B036,B038,B040,B042,B044,B046
0000846018 55555555 00000000 00000000 00000000 55555555 WB16c0     0 0010 040                                         B032,B034,B036,B038,B040,B042,B044,B046
0000846014 55555555 00000000 00000000 00000000 55555555 WB16a0     0 0010 040                                         B032,B034,B036,B038,B040,B042,B044,B046
0000846010 55555555 00000000 00000000 00000000 55555555 WB1680     0 0010 040                                         B032,B034,B036,B038,B040,B042,B044,B046
000084600c 55555555 00000000 00000000 00000000 55555555 WB1660     0 0010 040                                         B032,B034,B036,B038,B040,B042,B044,B046
0000846008 55555555 00000000 00000000 00000000 55555555 WB1640     0 0010 040                                         B032,B034,B036,B038,B040,B042,B044,B046
0000846004 55555555 00000000 00000000 00000000 55555555 WB1620     0 0010 040                                         B032,B034,B036,B038,B040,B042,B044,B046
0000846000 55555555 00000000 00000000 00000000 55555555 WB1600     0 0010 040                                         B032,B034,B036,B038,B040,B042,B044,B046
000084401c 55555555 00000000 00000000 00000000 55555555 WA12e0     2 0010 050                                         A032,A034,A036,A038,A040,A042,A044,A046
0000844018 55555555 00000000 00000000 00000000 55555555 WA12c0     2 0010 050                                         A032,A034,A036,A038,A040,A042,A044,A046
0000844014 55555555 00000000 00000000 00000000 55555555 WA12a0     2 0010 050                                         A032,A034,A036,A038,A040,A042,A044,A046
0000844010 55555555 00000000 00000000 00000000 55555555 WA1280     2 0010 050                                         A032,A034,A036,A038,A040,A042,A044,A046
000084400c 55555555 00000000 00000000 00000000 55555555 WA1260     2 0010 050                                         A032,A034,A036,A038,A040,A042,A044,A046
0000844008 55555555 00000000 00000000 00000000 55555555 WA1240     2 0010 050                                         A032,A034,A036,A038,A040,A042,A044,A046
0000844004 55555555 00000000 00000000 00000000 55555555 WA1220     2 0010 050                                         A032,A034,A036,A038,A040,A042,A044,A046
0000844000 55555555 00000000 00000000 00000000 55555555 WA1200     2 0010 050                                         A032,A034,A036,A038,A040,A042,A044,A046
000084201c 55555555 00000000 00000000 00000000 55555555 WB16e1     3 0010 050                                         B048,B050,B052,B054,B056,B058,B060,B062
0000842018 55555555 00000000 00000000 00000000 55555555 WB16c1     3 0010 050                                         B048,B050,B052,B054,B056,B058,B060,B062
0000842014 55555555 00000000 00000000 00000000 55555555 WB16a1     3 0010 050                                         B048,B050,B052,B054,B056,B058,B060,B062
0000842010 55555555 00000000 00000000 00000000 55555555 WB1681     3 0010 050                                         B048,B050,B052,B054,B056,B058,B060,B062
000084200c 55555555 00000000 00000000 00000000 55555555 WB1661     3 0010 050                                         B048,B050,B052,B054,B056,B058,B060,B062
0000842008 55555555 00000000 00000000 00000000 55555555 WB1641     3 0010 050                                         B048,B050,B052,B054,B056,B058,B060,B062
0000842004 55555555 00000000 00000000 00000000 55555555 WB1621     3 0010 050                                         B048,B050,B052,B054,B056,B058,B060,B062
0000842000 55555555 00000000 00000000 00000000 55555555 WB1601     3 0010 050                                         B048,B050,B052,B054,B056,B058,B060,B062
000084001c 55555555 00000000 00000000 00000000 55555555 WA12e1     1 0010 040                                         A048,A050,A052,A054,A056,A058,A060,A062
0000840018 55555555 00000000 00000000 00000000 55555555 WA12c1     1 0010 040                                         A048,A050,A052,A054,A056,A058,A060,A062
0000840014 55555555 00000000 00000000 00000000 55555555 WA12a1     1 0010 040                                         A048,A050,A052,A054,A056,A058,A060,A062
0000840010 55555555 00000000 00000000 00000000 55555555 WA1281     1 0010 040                                         A048,A050,A052,A054,A056,A058,A060,A062
000084000c 55555555 00000000 00000000 00000000 55555555 WA1261     1 0010 040                                         A048,A050,A052,A054,A056,A058,A060,A062
0000840008 55555555 00000000 00000000 00000000 55555555 WA1241     1 0010 040                                         A048,A050,A052,A054,A056,A058,A060,A062
0000840004 55555555 00000000 00000000 00000000 55555555 WA1221     1 0010 040                                         A048,A050,A052,A054,A056,A058,A060,A062
0000840000 55555555 00000000 00000000 00000000 55555555 WA1201     1 0010 040                                         A048,A050,A052,A054,A056,A058,A060,A062
000085e01c 55555555 00aaaaaa 00aaaaaa 00aaaaaa 55ffffff WA1be0     0 0010 040 A032,A033,A034,A035,A036,A037,A038,A039,A040,A041,A042,A043,A044,A045,A046,A047
000085e018 55555555 00aaaaaa 00aaaaaa 00aaaaaa 55ffffff WA1bc0     0 0010 040 A032,A033,A034,A035,A036,A037,A038,A039,A040,A041,A042,A043,A044,A045,A046,A047
000085e014 55555555 00aaaaaa 00aaaaaa 00aaaaaa 55ffffff WA1ba0     0 0010 040 A032,A033,A034,A035,A036,A037,A038,A039,A040,A041,A042,A043,A044,A045,A046,A047
000085e010 55555555 00aaaaaa 00aaaaaa 00aaaaaa 55ffffff WA1b80     0 0010 040 A032,A033,A034,A035,A036,A037,A038,A039,A040,A041,A042,A043,A044,A045,A046,A047
000085e00c 55555555 00aaaaaa 00aaaaaa 00aaaaaa 55ffffff WA1b60     0 0010 040 A032,A033,A034,A035,A036,A037,A038,A039,A040,A041,A042,A043,A044,A045,A046,A047
000085e008 55555555 00aaaaaa 00aaaaaa 00aaaaaa 55ffffff WA1b40     0 0010 040 A032,A033,A034,A035,A036,A037,A038,A039,A040,A041,A042,A043,A044,A045,A046,A047
000085e004 55555555 00aaaaaa 00aaaaaa 00aaaaaa 55ffffff WA1b20     0 0010 040 A032,A033,A034,A035,A036,A037,A038,A039,A040,A041,A042,A043,A044,A045,A046,A047
000085e000 55555555 00aaaaaa 00aaaaaa 00aaaaaa 55ffffff WA1b00     0 0010 040 A032,A033,A034,A035,A036,A037,A038,A039,A040,A041,A042,A043,A044,A045,A046,A047
000085c01c 55555555 00aaaaaa 00aaaaaa 00aaaaaa 55ffffff WB1fe0     2 0010 050 B032,B033,B034,B035,B036,B037,B038,B039,B040,B041,B042,B043,B044,B045,B046,B047
000085c018 55555555 00aaaaaa 00aaaaaa 00aaaaaa 55ffffff WB1fc0     2 0010 050 B032,B033,B034,B035,B036,B037,B038,B039,B040,B041,B042,B043,B044,B045,B046,B047
000085c014 55555555 00aaaaaa 00aaaaaa 00aaaaaa 55ffffff WB1fa0     2 0010 050 B032,B033,B034,B035,B036,B037,B038,B039,B040,B041,B042,B043,B044,B045,B046,B047
000085c010 55555555 00aaaaaa 00aaaaaa 00aaaaaa 55ffffff WB1f80     2 0010 050 B032,B033,B034,B035,B036,B037,B038,B039,B040,B041,B042,B043,B044,B045,B046,B047
000085c00c 55555555 00aaaaaa 00aaaaaa 00aaaaaa 55ffffff WB1f60     2 0010 050 B032,B033,B034,B035,B036,B037,B038,B039,B040,B041,B042,B043,B044,B045,B046,B047
000085c008 55555555 00aaaaaa 00aaaaaa 00aaaaaa 55ffffff WB1f40     2 0010 050 B032,B033,B034,B035,B036,B037,B038,B039,B040,B041,B042,B043,B044,B045,B046,B047
000085c004 55555555 00aaaaaa 00aaaaaa 00aaaaaa 55ffffff WB1f20     2 0010 050 B032,B033,B034,B035,B036,B037,B038,B039,B040,B041,B042,B043,B044,B045,B046,B047
000085c000 55555555 00aaaaaa 00aaaaaa 00aaaaaa 55ffffff WB1f00     2 0010 050 B032,B033,B034,B035,B036,B037,B038,B039,B040,B041,B042,B043,B044,B045,B046,B047
000085a01c 55555555 00000000 00000000 00000000 55555555 WA1be1     3 0010 050                                         A048,A050,A052,A054,A056,A058,A060,A062
000085a018 55555555 00000000 00000000 00000000 55555555 WA1bc1     3 0010 050                                         A048,A050,A052,A054,A056,A058,A060,A062
000085a014 55555555 00000000 00000000 00000000 55555555 WA1ba1     3 0010 050                                         A048,A050,A052,A054,A056,A058,A060,A062
000085a010 55555555 00000000 00000000 00000000 55555555 WA1b81     3 0010 050                                         A048,A050,A052,A054,A056,A058,A060,A062
000085a00c 55555555 00000000 00000000 00000000 55555555 WA1b61     3 0010 050                                         A048,A050,A052,A054,A056,A058,A060,A062
000085a008 55555555 00000000 00000000 00000000 55555555 WA1b41     3 0010 050                                         A048,A050,A052,A054,A056,A058,A060,A062
000085a004 55555555 00000000 00000000 00000000 55555555 WA1b21     3 0010 050                                         A048,A050,A052,A054,A056,A058,A060,A062
000085a000 55555555 00000000 00000000 00000000 55555555 WA1b01     3 0010 050                                         A048,A050,A052,A054,A056,A058,A060,A062
000085801c 55555555 00000000 00000000 00000000 55555555 WB1fe1     1 0010 040                                         B048,B050,B052,B054,B056,B058,B060,B062
0000858018 55555555 00000000 00000000 00000000 55555555 WB1fc1     1 0010 040                                         B048,B050,B052,B054,B056,B058,B060,B062
0000858014 55555555 00000000 00000000 00000000 55555555 WB1fa1     1 0010 040                                         B048,B050,B052,B054,B056,B058,B060,B062
0000858010 55555555 00000000 00000000 00000000 55555555 WB1f81     1 0010 040                                         B048,B050,B052,B054,B056,B058,B060,B062
000085800c 55555555 00000000 00000000 00000000 55555555 WB1f61     1 0010 040                                         B048,B050,B052,B054,B056,B058,B060,B062
0000858008 55555555 00000000 00000000 00000000 55555555 WB1f41     1 0010 040                                         B048,B050,B052,B054,B056,B058,B060,B062
0000858004 55555555 00000000 00000000 00000000 55555555 WB1f21     1 0010 040                                         B048,B050,B052,B054,B056,B058,B060,B062
0000858000 55555555 00000000 00000000 00000000 55555555 WB1f01     1 0010 040                                         B048,B050,B052,B054,B056,B058,B060,B062
000085601c 55555555 00000000 00000000 00000000 55555555 WA03e1     1 0010 040                                         A016,A018,A020,A022,A024,A026,A028,A030
0000856018 55555555 00000000 00000000 00000000 55555555 WA03c1     1 0010 040                                         A016,A018,A020,A022,A024,A026,A028,A030
0000856014 55555555 00000000 00000000 00000000 55555555 WA03a1     1 0010 040                                         A016,A018,A020,A022,A024,A026,A028,A030
0000856010 55555555 00000000 00000000 00000000 55555555 WA0381     1 0010 040                                         A016,A018,A020,A022,A024,A026,A028,A030
000085600c 55555555 00000000 00000000 00000000 55555555 WA0361     1 0010 040                                         A016,A018,A020,A022,A024,A026,A028,A030
0000856008 55555555 00000000 00000000 00000000 55555555 WA0341     1 0010 040                                         A016,A018,A020,A022,A024,A026,A028,A030
0000856004 55555555 00000000 00000000 00000000 55555555 WA0321     1 0010 040                                         A016,A018,A020,A022,A024,A026,A028,A030
0000856000 55555555 00000000 00000000 00000000 55555555 WA0301     1 0010 040                                         A016,A018,A020,A022,A024,A026,A028,A030
000085401c 55555555 00000000 00000000 00000000 55555555 WB07e1     3 0010 050                                         B016,B018,B020,B022,B024,B026,B028,B030
0000854018 55555555 00000000 00000000 00000000 55555555 WB07c1     3 0010 050                                         B016,B018,B020,B022,B024,B026,B028,B030
0000854014 55555555 00000000 00000000 00000000 55555555 WB07a1     3 0010 050                                         B016,B018,B020,B022,B024,B026,B028,B030
0000854010 55555555 00000000 00000000 00000000 55555555 WB0781     3 0010 050                                         B016,B018,B020,B022,B024,B026,B028,B030
000085400c 55555555 00000000 00000000 00000000 55555555 WB0761     3 0010 050                                         B016,B018,B020,B022,B024,B026,B028,B030
0000854008 55555555 00000000 00000000 00000000 55555555 WB0741     3 0010 050                                         B016,B018,B020,B022,B024,B026,B028,B030
0000854004 55555555 00000000 00000000 00000000 55555555 WB0721     3 0010 050                                         B016,B018,B020,B022,B024,B026,B028,B030
0000854000 55555555 00000000 00000000 00000000 55555555 WB0701     3 0010 050                                         B016,B018,B020,B022,B024,B026,B028,B030
000085201c 55555555 00000000 00000000 00000000 55555555 WA03e0     2 0010 050                                         A000,A002,A004,A006,A008,A010,A012,A014
0000852018 55555555 00000000 00000000 00000000 55555555 WA03c0     2 0010 050                                         A000,A002,A004,A006,A008,A010,A012,A014
0000852014 55555555 00000000 00000000 00000000 55555555 WA03a0     2 0010 050                                         A000,A002,A004,A006,A008,A010,A012,A014
0000852010 55555555 00000000 00000000 00000000 55555555 WA0380     2 0010 050                                         A000,A002,A004,A006,A008,A010,A012,A014
000085200c 55555555 00000000 00000000 00000000 55555555 WA0360     2 0010 050                                         A000,A002,A004,A006,A008,A010,A012,A014
0000852008 55555555 00000000 00000000 00000000 55555555 WA0340     2 0010 050                                         A000,A002,A004,A006,A008,A010,A012,A014
0000852004 55555555 00000000 00000000 00000000 55555555 WA0320     2 0010 050                                         A000,A002,A004,A006,A008,A010,A012,A014
0000852000 55555555 00000000 00000000 00000000 55555555 WA0300     2 0010 050                                         A000,A002,A004,A006,A008,A010,A012,A014
000085001c 55555555 00000000 00000000 00000000 55555555 WB07e0     0 0010 040                                         B000,B002,B004,B006,B008,B010,B012,B014
0000850018 55555555 00000000 00000000 00000000 55555555 WB07c0     0 0010 040                                         B000,B002,B004,B006,B008,B010,B012,B014
0000850014 55555555 00000000 00000000 00000000 55555555 WB07a0     0 0010 040                                         B000,B002,B004,B006,B008,B010,B012,B014
0000850010 55555555 00000000 00000000 00000000 55555555 WB0780     0 0010 040                                         B000,B002,B004,B006,B008,B010,B012,B014
000085000c 55555555 00000000 00000000 00000000 55555555 WB0760     0 0010 040                                         B000,B002,B004,B006,B008,B010,B012,B014
0000850008 55555555 00000000 00000000 00000000 55555555 WB0740     0 0010 040                                         B000,B002,B004,B006,B008,B010,B012,B014
0000850004 55555555 00000000 00000000 00000000 55555555 WB0720     0 0010 040                                         B000,B002,B004,B006,B008,B010,B012,B014
0000850000 55555555 00000000 00000000 00000000 55555555 WB0700     0 0010 040                                         B000,B002,B004,B006,B008,B010,B012,B014
If you are getting failure for first MB of FB then try option -no_scan_out
Error Code = 00000001


 #######     ####    ########  ###
 #######    ######   ########  ###
 ##        ##    ##     ##     ###
 ##        ##    ##     ##     ###
 #######   ########     ##     ###
 #######   ########     ##     ###
 ##        ##    ##     ##     ###
 ##        ##    ##  ########  ########
 ##        ##    ##  ########  ########

Chatgpt sugeruje, że powinienem zrobić jakieś sudo, ale karta już wyjęta i chyba niewiele by to zmieniło.

mods.log nvmt.log Primary_Report.txt

Edytowane 19 Czerwca przez Pentium D

**Pentium D** · 19 Czerwca

Z tą 4060 nic nie zrobię a coś pogrzebać trzeba było więc postanowiłem dać radiator z rx 560 na gt430. Niby wszystko pasowało, ale rurka cieplna zahaczała o cewkę i coś mi się ubzdurało aby cewkę przerzucić na drugą stronę pcb. Gdy to zrobiłem dotarło do mnie że rurki mogą być za blisko płyty głównej więc wykorzystałem inne otwory na śrubki w radiatorze. Czemu tego nie zrobiłem na początku nie wiem. Oszczędził bym sobie lutowania. Dałem podkładki z karty telefonicznej bo się trochę gibał radiator. Niestety nie da się założyć wentylatorów bo jest za blisko śledzia, ale i tak wygląda fajnie.

**Pentium D** · 20 Czerwca

Dzisiaj przyszła karta R9 380X i chciałem od razu sprawdzić czy jest git oraz chciałem odpalić zestaw na z87 aby pobawić się i5 4670K w jakieś OC i mnie pokarało. Dysk m.2 przez adapter pcie nie działał. Wziąłem z laptopa ssd na sata 6 Gb i ten też nie chciał działać normalnie podpięty. Dawał błędem "Inaccessible Boot Device". Podpiąłem go jak zewnętrzny przez USB to przynajmniej pokazał się ekran logowania, ale nie dało się zalogować ani kodem pin ani hasłem na konto Microsoft. No patologia. Postawiłem system na nowo i trochę szok jak to szybko się zainstalowało. System też szybko wstaje i jest zaskakująco responsywny. Zainstalowałem sterowniki i w GPUz widzę że karta chodzi na max 3.0 x4. Pomyślałem, że wina brudu bo mocno ukurzona. Wyjąłem, wsadzam ponownie i tym razem już było x8, nadal za mało. Wyciągam, patrzę a tam przetrącony element. Nie wiem czy to tak do mnie wysłano czy ja to zrobiłem, bez znaczenia. Już miałem ochotę to zostawić, ale nie zasnąłbym. Oryginalny element oczywiście zgubiłem więc ukradłem jeden z HD5450 xd. Tak ładnie wyszło że nie widać że coś było robione. Jest pełne x16.

Edytowane 20 Czerwca przez Pentium D

**Pentium D** · 21 Czerwca

Karta odkurzona, pasta i pady wymienione. Chyba jeszcze pamiętały fabrykę bo pasta twarda jak kamień. Dodałem też pady pod pamięci i sekcję zasilania między pcb a backplate. Nie kumam tego jak można dać aluminiowy backplate i nie dać tam żadnego pada tylko nakleić folię aby zaizolować i cześć. Chcą aby backplate tylko robił za ochronę przed urwaniem czegoś albo dodatek wizualny to niech dadzą plastikowy i niższą cenę.

Zaraz odpalam kompa i zobaczymy czy to działa.

**Pentium D** · 21 Czerwca

Ehh, jedno naprawie to inne popsuje.

Chciałem sprawdzić jakie temperatury osiąga gt430 na tym nowym radiatorze i zaczęło walić artefaktami.

Grzałem rdzeń i bez zmian. Grzałem vram, bez zmian. Obejrzałem rdzeń i róg ukruszony, ale czy na tyle aby dawał taki obraz :hmm:

Po zabawie z lutowaniem cewki karty nie sprawdzałem od razu. Może ten kondensator obok oberwał i coś źle podaje. Nie mam pojęcia.

Edit: podgrzałem rdzeń jeszcze raz i teraz już obrazu nie daje, ale grzeje się mocno. Sygnału z bios wskazują na problem z GPU. Wcześniej tak nie było. RIP.

Edytowane 21 Czerwca przez Pentium D

**Pentium D** · 21 Czerwca

Jako że udało mi się zepsuć gt 430 to wlatują trzy RX 580 8 GB 2048 po 59 zł sztuka i wszystkie sprawne pod kątem rdzenia i pamięci, ale w jednym chyba jest rozszczelniony heatpipe a pozostałe też się grzeją bo cooler jest nieadekwatny do mocy karty. W mały cooler leci moc z GPU, pamięci, i sekcji zasilania. Musiało być coś palone aby to tak wykombinować.

5 mm czy więcej?

**Mar_s** · 23 Czerwca

Gdzie Ty łapiesz w takich cenach?

**Pentium D** · 23 Czerwca

@Mar_s Wyszukuje się, kombinuje, potrzeba kilka telefonów i e-maili.

Edytowane 23 Czerwca przez Pentium D

**Mar_s** · 23 Czerwca

Han Solo.

W takim razie te karty pewnie najszybsze w całej galaktyce.

ShaDow_Pro · 23 Czerwca

Za imię i nazwisko zasłużony plusik

**Pentium D** · 25 Czerwca

Dzisiaj chciałem założyć jakieś chłodzenie na tego rx 580 z uszkodzonym heatpipem. Początkowo chciałem użyć chłodzenia z 270X ale stanęło na tym z rx 560. Mniej roboty bo wystarczyło eksmitować kondensator. Wyszło nieźle. Sam radiator cięższy o 14%, ale wentylatory o trochę mniejszej średnicy. Musiałem zamienić wentylatory miejscami aby sięgnąć do gniazda zasilania. Kilka kostek ramu łapie się na kawałek radiatora. Do radiatora dokleiłem podkładki metalowe aby był jakiś stoper żeby nie ściągnąć cooler za mocno, ale w sumie opiera się trochę na pamięciach i jest ograniczenie na gwintach śrubek, ale lepiej mieć niż nie mieć. Pasta ładnie siada na rdzeniu. Sprawdzę ją kiedyś jak rozłożę zestaw testowy.

Edytowane 25 Czerwca przez Pentium D

sideband · 25 Czerwca

Ja pitole przecież dało się to zrobić dużo lepiej.

Kondensator na na kablach Podejrzewam, że te kable mają większe rezystancje jak ESR tego kondensatora

**Pentium D** · 25 Czerwca

@sideband niby jak lepiej ? miejsca nie ma a dawać na tył nie chciałem.

Kabelek od przycisku resetu.

Kurna. Teraz sobie uświadomiłem, że te druty mogą być czymś pokryte a ja ich nie obdrapałem i miernikiem nie sprawdziłem czy jest przejście

Edytowane 25 Czerwca przez Pentium D

sideband · 25 Czerwca

Na rewersie wlutowujesz na leżąco w to miejsce i dajesz kropelkę silikonu pod kondensator.

A jak masz z czego dobierasz i wrzucasz polimero-tantala w to miejsce, który jest znacznie mniejszy.

**Pentium D** · 25 Czerwca

W sumie spoko pomysł, ale wątpię abym miał na którymś z dawców odpowiedni kondensator.

Chyba nie ma tantalowego o pojemności 820 µF ale chyba można dać równolegle 330 i 470 i wyjdzie prawie to samo :hmm:

Edytowane 25 Czerwca przez Pentium D

**Mar_s** · 25 Czerwca

Nie załamuj się Pentiak, z Tesli też kiedyś kpili, a zoba teraz!

**Pentium D** · 25 Czerwca

1 minutę temu, Mar_s napisał(a):

Nie załamuj się Pentiak, z Tesli też kiedyś kpili, a zoba teraz!

No szukam teraz czy dałoby się to zrobić lepiej, ale chyba się nie da.

galakty · 25 Czerwca

Panie, lepiej to się nie da, niejeden inżynier by był w szoku jak dobrze zrobiłeś.

sideband · 25 Czerwca

58 minut temu, Pentium D napisał(a):

W sumie spoko pomysł, ale wątpię abym miał na którymś z dawców odpowiedni kondensator.

Chyba nie ma tantalowego o pojemności 820 µF ale chyba można dać równolegle 330 i 470 i wyjdzie prawie to samo

Pojemność jest drugorzędna istotne jest ESR jak wstawisz o za wysokim ESR skończy znacznie większymi tętnieniami lub wywali go po czasie - zrobi zwarcie i dopiero się zrobi kipisz.

Edytowane 25 Czerwca przez sideband

**Mar_s** · 25 Czerwca

53 minuty temu, galakty napisał(a):

Panie, lepiej to się nie da, niejeden inżynier by był w szoku jak dobrze zrobiłeś.

Potwierdzam, byłem w szoku jak zobaczyłem.

57 minut temu, Pentium D napisał(a):

No szukam teraz czy dałoby się to zrobić lepiej, ale chyba się nie da.

Miałbyś dremelka to byś machnął kawałek radiatora.

Zaloguj się

Zdrutowane przez Pentiuma

Rekomendowane odpowiedzi

Pan Ciastovy 92

Top użytkownicy w tym temacie

Popularne dni

Top użytkownicy w tym temacie

Popularne dni

Popularne posty

Pentium D

Pentium D

Pentium D

Opublikowane grafiki

Grolshek 516

Pentium D 1 159

Pan Ciastovy 92

sideband 1 772

Pentium D 1 159

Pentium D 1 159

Pentium D 1 159

Pentium D 1 159

Pentium D 1 159

Pentium D 1 159

Mar_s 2 226

Pentium D 1 159

Mar_s 2 226

ShaDow_Pro 560

Pentium D 1 159

sideband 1 772

Pentium D 1 159

sideband 1 772

Pentium D 1 159

Mar_s 2 226

Pentium D 1 159

galakty 3 312

sideband 1 772

Mar_s 2 226

Jeśli chcesz dodać odpowiedź, zaloguj się lub zarejestruj nowe konto

Zarejestruj nowe konto

Zaloguj się

Ostatnio przeglądający 0 użytkowników

Popularne tematy

Najnowsze posty

Aktywni użytkownicy
